功能性无水炮泥采用原料均化和微粉预混技术,用特制复合原料作为外加剂,有良好的抗蚀性,填充性和烧结性等优良的性能,对铁口裂纹有强制修复功能,它能在铁口迅速产生一定的抗机械和化学损毁的能力,高温强度与残余炮泥结合性好,而出铁时又容易开口并保证铁水和熔渣快通过时冲蚀小,是铁水和熔渣的流动平稳,顺畅,从而抑制了炉内熔渣和铁水的环流,减轻了出铁口周围炉底侧的衬砖损蚀,很好的保护了高炉铁口区域的炉衬及炉缸,有益于延长高炉炉体寿命。
This product uses raw material homogenization and fine powder pre-mixing technology, and uses special composite raw materials as admixtures. It has good properties such as good corrosion resistance, filling properties and sinterability. It has a mandatory repair function for iron cracks. The mouth quickly produces a certain ability to resist mechanical and chemical damage. The high temperature strength is good in combination with the residual gun mud. It is easy to open when the iron is tapped and ensures that the molten iron and slag pass through quickly. It is the flow of molten iron and slag. Smooth and smooth, thereby suppressing the circulation of molten slag and molten iron in the furnace, reducing the corrosion of the lining bricks around the bottom of the furnace, and protecting the lining and hearth of the blast furnace iron mouth area, which is beneficial to extend the blast furnace Furnace life.
强制修复型炮泥理化指标 Non -water Tap Hole Clay with Compulsory Repair Function
项目 |
化学组成% |
耐压强度 Mpa Crushing strength |
抗折强度MPa Bending strength |
线变化率% Linear change |
体积密度g/cm3 Bulk density |
应 用 |
|||
Al2O3 |
SiC |
FC |
200℃×24h |
1350℃×3h |
1350℃×3h |
1350℃×3h |
1350℃×3h |
||
HXPN-GI |
≥40 |
≥15 |
≥13 |
≥4.5 |
≥15 |
≥4 |
±1 |
≥1.8 |
大型高炉 |
HXPN-G2 |
≥36 |
≥12 |
≥11 |
≥4 |
≥12 |
≥3.8 |
±1.45 |
≥1.7 |
中型高炉 |
HXPN-G3 |
≥32 |
≥10 |
≥9 |
≥3 |
≥9 |
≥3.2 |
±1.5 |
≥1.65 |
小型高炉 |
备注 |
此技术参数仅供参考,针对高炉的使用效果需要研究其冶炼产物和操作方式,炉况予以调整。 This indicator is for reference only. For the use effect of the blast furnace, its smelting products and operation methods need to be studied, and the furnace conditions are adjusted |
功能性延缓炉龄寿命炮泥 HIgh-strength & Functional Tap Hole Clay Lengthenning Campaign Life
项目 Item |
化学组成% Chem .comp |
耐压强度MPa Crushing strength |
线变化率% Linear change |
体积密度g/cm3 |
显气孔率% Apparent porosity |
马夏值Mpa
|
|
Al2O3 |
Sic+C |
1350℃×3h |
1350℃×3h |
1350℃×3h |
常温 Normal Temperature |
常温 Normal Temperature |
|
HXPN-G4 |
≥38 |
≥30 |
≥8 |
±1.35 |
≥1.7 |
≥30 |
0.5-0.7 |
备注 |
此技术参数仅供参考,针对高炉的使用效果需要研究其冶炼产物和操作方式,炉况予以调整。 This indicator is for reference only. For the use effect of the blast furnace, its smelting products and operation methods need to be studied, and the furnace conditions are adjusted |
